Cradlepoint IBR200
Cloud-Managed Networking for IoT

Cradlepoint IBR200

Cradlepoint Products
NetCloud Essentials for IoT Gateways (Standard) with IBR200-10M for Verizon
NetCloud Essentials for IoT Gateways (Standard) with IBR200-10M for VZ 1-yr
1-yr NetCloud Essentials for IoT Gateways (Standard) with support and IBR200 router with WiFi (10 Mbps modem) for Verizon
#TA1-020010M-VNN
Our Price: $279.00
NetCloud Essentials for IoT Gateways (Standard) with IBR200-10M for VZ 3-yr
3-yr NetCloud Essentials for IoT Gateways (Standard) with support and IBR200 router with WiFi (10 Mbps modem) for Verizon
#TA3-020010M-VNN
Our Price: $339.00
NetCloud Essentials for IoT Gateways (Standard) with IBR200-10M for VZ 5-yr
5-yr NetCloud Essentials for IoT Gateways (Standard) with support and IBR200 router with WiFi (10 Mbps modem) for Verizon
#TA5-020010M-VNN
Our Price: $399.00

Click here to jump to more pricing!

Overview:

The vast potential of IoT to enable new business opportunities, streamline operations, and reduce costs is accompanied by significant IT challenges, including the diversity and widespread distribution of IoT devices, the need for a pervasive and elastic wireless WAN with more intelligence at the edge, and far-reaching security implications.

overview

Cradlepoint’s Elastic EdgeSM vision provides a blueprint for next-generation IoT networks that deliver pervasive wireless connectivity, cloud-like scale and agility, and edge extensibility — together with the visibility, security, and control that IT requires. All-inclusive NetCloud Solution Packages for IoT Networks, based on Cradlepoint's industry-leading 4G LTE routers, are flexible, and include cloud-based management.

Features:

WAN:

  • Cat 1 LTE
  • Advanced Modem Failure Check
  • Failover/Failback
  • Standby
  • WiFi as WAN
  • IP Passthrough

LAN:

  • VLAN 802.1Q
  • DHCP Server, Client, Relay
  • DNS and DNS Proxy
  • STP
  • Multicast/Multicast Proxy

WIFI:

  • 802.11 1×1 b/g/n 2.4 GHz
  • Up to 16 connected devices
  • 2 SSIDs
  • WPA2 Enterprise
  • DynDNS
  • AutoQoS
  • QoS (DSCP and Priority Queuing)

MANAGEMENT:

  • Cradlepoint NetCloud Manager
  • Web UI, API, CLI
  • Data Usage Alerts (router and per client)
  • Advanced troubleshooting (support)
  • Device alerts
  • SNMP
  • SMS control
  • Remote Connect / OOBM
  • Client Visibility Control
  • Pool data alerts
  • SDK support

VPN & ROUTING

  • IPsec Tunnel – up to two concurrent sessions
  • IKEv2 support (includes MOBIKE)
  • GRE Tunnel
  • WAN Affinity
  • NAT-less Routing
  • Virtual Server/Port Forwarding
  • IPv6

SECURITY:

  • RADIUS and TACACS+ support*
  • 802.1x authentication for Ethernet
  • Certificate support
  • ALGs
  • MAC Address Filtering
  • Advanced Security Mode (local user management only)
  • Per-Client Web Filtering
  • IP Filtering
  • Content Filtering (basic)
  • Website Filtering
  • Zone-Based Object Firewall with host address (IP or FQDN), port, and mac address
  • NetCloud Perimeter compatible

Specifications:


Cradlepoint IBR200 Series Specifications
WAN
  • Cat 1 LTE modem
  • One SIM slot
LAN One LAN 10/100 Ethernet port
Ports
  • Power
  • One Ethernet LAN
  • Two cellular antenna connectors (SMA)
  • One WiFi connectors (reverse SMA)
  • 2-wire GPIO (one input, one output)
Temperature –20 °C to 60 °C (–4 °F to 140 °F) operating
Humidity (non-condensing)
  • 5% to 95% operating
  • 5% to 95% storage
Power
  • 12 VDC / 1 A adapter
  • Reverse polarity and transient voltage protection per ISO 7637-2
  • Power consumption:
    • Conditions: 12V input, room temperature
    • Idle: 2.7W (1.8W w/WiFi off)
    • Typical: 3.6 W (2.8W w/WiFi off)
    • Heavy Usage: TBD
WIFI POWER (FCC): 2402–2483.5 MHz (2.4 GHz band): 25.3 dBm conducted
Size: 3.0 × 3.7 × 1.0 in (76.5 × 94.5 × 24.5 mm)
Weight: 6 oz (175 g)
Certifications:
  • PTCRB, FCC, IC, Carrier
  • Safety: UL/CUL
  • Materials: WEEE, RoHS, RoHS-2, California Prop 65
Accessories
  • Directional Patch antennas for external (outside) mounting (Part # 170587-000)
  • Directional Yagi (Log-Periodic) antennas for external (outside) mounting (Part # 170588-000)
  • Omni-directional antennas for external (outside) mounting (Part # 170586-000)
  • 12” Mag-mount antenna (Part # 170605-000)
  • 4” Mini mag-mount antenna (Part # 170606-000)
  • Barrel to 4-pin power adapter (Part # 170665-000)
  • Replacement mini cellular antenna Part #: (170704-002)

Software:

Cradlepoint’s NetCloud

Cloud Networking for Branch Office, Retail, and More

Cradlepoint’s NetCloud platform includes an industryleading router operating system, an award-winning management platform optimized for cellular, and virtual private cloud networking. When combined with Cradlepoint routers, this integrated platform of flexible, extensible, and rapidly deployable applications enables an entirely new way to easily build, secure, control, and manage end-to-end private networks in the cloud.

NetCloud OS

Firewall, Advanced Routing-Optimized for LTE
NetCloud OS is the heart of our industry-leading LTE routers. Sustained commitment to new features and capabilities ensures your network is always up to date and secure.

NetCloud Manager

Quickly Deploy, Manage & Monitor Your Network
NetCloud Manager is a cloud management service that enables zero-touch deployment, remote management, alerting, and network analytics for all Cradlepoint routers.

NetCloud Engine

Software-Defined. Security-Driven. Cloud-Delivered.
NetCloud Engine leverages SoftwareDefined Networking (SDN) to instantly create secure Virtual Cloud Networks over more cost-effective wired and wireless broadband Internet services.

Security Applications

Enhance network security with best-in-class applications from Cradlepoint Technology Partners. Create, deploy, and manage network security applications at remote locations with the Cradlepoint NetCloud platform. Improve productivity, reduce costs, and enhance the security intelligence of your network.

Zscaler Internet SecurityZscaler Internet Security

Configured in minutes, best-inclass Zscaler Internet Security protects your organization from web-based threats.

CP Secure Threat ManagementCP Secure Threat Management

A comprehensive intrusion prevention and detection system (IPS/IDS) for full defense-in-depth.

AER Platform Extensibility
AER Platform Extensibility

Cradlepoint Extensibility enables customers and developers to build one-of-a-kind applications and vertical solutions by extending key elements of the Cradlepoint platform. By leveraging our hardware, firmware, and cloud services, developers can add differentiation and unique value to the solutions they offer.

Router SDK (Open Beta)
Build custom vertical applications securely running at the Edge, protected on device, and deployed through the cloud. Manage, deploy, and monitor customer Edge applications from the cloud across the entire fleet.

NetCloud API
Cradlepoint’s API provides the building blocks developers need to craft applications that access the data from a software platform.

Developer Community (Open Beta)
The Cradlepoint Developer Community enables members to leverage knowledge, share, and collaborate with other developers.

CradleCare Support:

CradleCare SupportFrom initial device deployment to long-term operations, Cradlepoint Global Support offers world-class resources and expertise to keep your network secure, simple and efficient. Cradlepoint offers multiple tiers of support to provide you exactly what you need.

With Cradlepoint Global Support and CradleCare, you can:

  • Maximize revenue through always-on uptime and response times
  • Save time with our web-based Connect Portal and Knowledge Base
  • Collaborate with our multi-certified technical team
  • Maintain PCI Compliance with up-to-date router and modem firmware

The following chart provides an overview of Cradlepoint's support and maintenance offerings:

Included with every Cradlepoint purchase CradleCare Basic CradleCare

Web-based Cradlepoint Connect Portal:

  • 24x7x365 access to our Knowledge Base and Firmware download library
  • 12x5 email support (for Enterprise Cloud Manager and NetCloud Gateway only)
  • Knowledge Base access
  • Firmware upgrades
  • Standard warranty with extended warranty options

Included +

  • Covers all products and services
  • 12x5 phone, email and chat support for Cradlepoint routers, ECM and NetCloud Gateway
  • Knowledge Base access
  • Firmware upgrades
  • Standard warranty with extended warranty options

CradleCare Basic +

  • 24x7 qualified phone support and 12x5 email/chat support for Cradlepoint routers, ECM and NetCloud Gateway
  • Advanced Exchange: Next business day replacement
  • Service level targets
  • Assigned Enterprise Support Engineer (for deployments of 50 routers or more)
  • Enterprise engineering resources for network design and best practices implementation
  • Priority consideration of future feature requests and beta trials
  • Knowledge Base access
  • Firmware upgrades
  • Extended Warranty for routers for the term of CradleCare license

Extended Warranties

Extended Warranties can be purchased in subsequent years, and as a follow-on warranty at the conclusion of the standard warranty period. No gap in coverage is allowed: the new warranty must be in place before the existing warranty expires.

Standard One-Year Warranty (With Extended Warranty Option) Includes:

  • Access to Cradlepoint Connect portal and Knowledge Base
  • Hardware repair/replacement with 3-5 day shipping
  • Software bug fixes
  • An option to extend your warranty to 2, 3, or 5 years at the conclusion of the standard warranty period*

*Hardware warranties cannot be extended beyond 5 years from the date of purchase.

Documentation:

Download the Cradlepoint COR Series Datasheet (.PDF)

Download the Cradlepoint IBR200 Spec Sheet (.PDF)
